AGFRC A06CLS V2 — 7 g programmable micro digital servo with titanium gears, CNC aluminium case, and 20T spline (JST 1.5 plug). Purple edition of the same Mini-Z / 1/28 steering upgrade as the black A06CLS V2.
High-speed micro servo for Mini-Z (purple)
The A06CLS V2 delivers 3.0 kg·cm torque and 0.052 s/60° speed at 8.4V in a 20 × 8 × 17.8 mm package. Ball-bearing, metal gear train with 20T / 4.0 mm output spline — fits standard Mini-Z horn patterns with the included arm kit.
Same specs as the black edition — purple CNC case only. Programmable via the optional AGFRC AGF-SPV3 USB programmer (direction, endpoints, speed, torque, and more).
In the box
Servo with JST 1.5 lead and accessory horn/arm kit.
Specifications
| Model | A06CLS V2 (Purple, 20T) |
| Supplier SKU | A06CLSV2-P |
| Voltage | 4.8–8.4V HV |
| Speed @ 8.4V | 0.052 s/60° |
| Torque @ 8.4V | 3.0 kg·cm (41 oz·in) |
| Gear material | Titanium |
| Bearing | Ball bearing (BB) |
| Output spline | 20T, ø 4.0 mm |
| Connector | JST 1.5 plug |
| Size | 20 × 8 × 17.8 mm |
| Weight | 7 g |
| Brand | AGFRC |
